RAZZA - Horizontal Windlass
Lofrans’ Razza Windlass - Minimal Footprint, Real Power
Main Features:
• Marine-grade AISI 316L stainless steel construction with premium mirror-polished finish
• Compact low-profile horizontal windlass design with minimal footprint
• Seamless integration into modern deck layouts without sacrificing deck space
• Built on over 60 years of Lofrans anchoring expertise
• Available with real 500W and 800W power motor options, for uncompromising performance
• Manual chain release also available
• Delivered with rocker switch
• Chain counter sensor & magnet pre-installed for simplified installation and enhanced precision
• Spring-loaded finger for smooth and controlled chain & rope management
• Gypsy for chain & rope
• IP67 motor cover
• Ideal for boats up to 40 feet
Standard Equipment:
• Dual direction solenoid pack
• Handle
• Gypsy for chain & rope
• QR code for instruction manual
| Code | Description | Motor size | Power Supply | Maximum Pull | Working load (kg) | Amps at Working Load (A) | Line Speed at W.L | Max Line Speed | Net Weight | Gypsy For Chain | Gypsy For Rope |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 600135 | WINDLASS H. RAZZA INOX 500W/12V 7mmISO-1/4" G40 | 800 W | 12 V | 900 kg | 125 kg | 80 | 20 m/min | 25 m/min | 13,5 kg | 7 mm, ISO 4565 | 10-12-14 mm, 3-strand |
| 600136 | WINDLASS H. RAZZA INOX 800W/12V 7mmISO-1/4" G40 | 500 W | 12 V | 630 kg | 95 kg | 65 | 18 m/min | 24 m/min | 13,5 kg | 7 mm, ISO 4565 | 10-12-14 mm, 3-strand |
| 636699 | WINDLASS H. RAZZA INOX 800W/12V 8-5/16"BBB-5/16"HT | 800 W | 12 V | 900 kg | 125 kg | 80 | 20 m/min | 25 m/min | 13,5 kg | 8 mm, ISO 4565/ DIN 766 | 12 mm, 3-strand |
| 636738 | WINDLASS H. RAZZA INOX 500W/12V 6-3/16"BBB | 500 W | 12 V | 630 kg | 95 kg | 65 | 18 m/min | 24 m/min | 13,5 kg | 6 mm, ISO 4565 | 10-12 mm, 3-strand |
| 636739 | WINDLASS H. RAZZA INOX 500W/12V 8-5/16"BBB-5/16"HT | 500 W | 12 V | 630 kg | 95 kg | 65 | 18 m/min | 24 m/min | 13,5 kg | 8 mm, ISO 4565/ DIN 766 | 12 mm, 3-strand |
| 636740 | WINDLASS H. RAZZA INOX 800W/12V 6-3/16"BBB | 800 W | 12 V | 900 kg | 125 kg | 80 | 20 m/min | 25 m/min | 13,5 kg | 6 mm, ISO 4565 | 10-12 mm, 3-strand |
