XP800 - Vertical Windlass

Main features:

Features a vertical planetary gearmotor for easy installation on deck, even by a single person
The simple footprint utilises standardised hole saw drills for faster installation on board
Easy installation, even by one person
Marine stainless steel construction
Manual chain release
Pre-installed chain counter sensor
With electric break for anchor lock when not in use

Standard Equipment:

Handle
Pressure finger
Control box
Thermal circuit breaker
Lofrans’ rocker switch

It provides a maximum pull of 320 kg making it an ideal anchoring system solution for small vessels up to 11 meters / 36 feet.

Get in touch

Code	Description	Power Supply	Maximum Pull	Working load (kg)	Amps at Working Load (A)	Line Speed at W.L	Max Line Speed	Circuit Breaker	Control Box	Gypsy For Chain	Gypsy For Rope
	WINDLASS V. XP800 ΙΝΟΧ 500W/12V 6-3/16'' BBB	12V	320kg	95kg	35A	17m/min	21m/min	25A	Included in the package	6mm	10-12mm 3-strand
	WINDLASS V. XP800 ΙΝΟΧ 500W/12V 7-1/4" HT	12V	320kg	95kg	35A	17m/min	21m/min	25A	Included in the package	7mm	10-12mm 3-strand
	WINDLASS V. XP800 ΙΝΟΧ 500W/12V 8-5/16 BBB-5/16 HT	12V	320kg	95kg	35A	17m/min	21m/min	25A	Included in the package	8mm	12-14mm 3-strand
