Capstan T500
Main Features
- Luxury chrome bronze base and drum
- Heavy duty rated IP67 electric motor
- Anodised marine aluminium gearbox
- Control Box included in package
| Code | Description | Construction | Motor size | Power Supply | Maximum Pull | Working load (kg) | Amps at Working Load (A) | Line Speed at W.L | Max Line Speed | Net Weight | Circuit Breaker |
|---|---|---|---|---|---|---|---|---|---|---|---|
![[] CAPSTAN T500 CRO STD 500W/12V image](https://www.lofrans.com/images/items/itm_CapstanT500-1700.jpg)
|
CAPSTAN T500 CRO STD 500W/12V | Chromed bronze | 500 W | 12 V | 630 kg | 70 | 75 | 23 m/min | 26 m/min | 11 kg | 187331 |
|
|
CAPSTAN T500 ALU STD 500W/12V | Aluminium | 500 W | 12 V | 630 kg | 70 | 75 | 23 m/min | 26 m/min | 9 kg | 187331 |
3D Models
Deck Templates
