Capstan T2000
Main Features
- Luxury chromed bronze construction base and drum
- Heavy duty electric motor
- Anodised marine aluminium gearbox
| Code | Description | Motor size | Power Supply | Maximum Pull | Working load (kg) | Amps at Working Load (A) | Line Speed at W.L | Max Line Speed | Net Weight | Control Box | Hydraulic Pressure | Hydraulic Flow | Pull Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![[] CAPSTAN T2000 CRO STD 2300W/24V image](https://www.lofrans.com/images/items/itm_CapstanT2500.jpg)
|
CAPSTAN T2000 CRO STD 2300W/24V | 2300 W | 24 V | 2000 kg | 410 | 180 | 15 m/min | 31 m/min | 52 kg | Included in package | - | - | CW |
![[] CAPSTAN T2000 CRO STD 2200W/400V image](https://www.lofrans.com/images/items/itm_CapstanT2000.jpg)
|
CAPSTAN T2000 CRO STD 2200W/400V | 2200 W | 400 V | 2000 kg | 410 | - | 15 m/min | 15 m/min | 52 kg | Switchboard available separately | - | - | CW |
|
|
CAPSTAN T2000 CRO POR 2300W/24V | 2300 W | 24 V | 2000 kg | 410 | 180 | 15 m/min | 31 m/min | 52 kg | Included in package | - | - | CCW |
|
|
CAPSTAN T2000 CRO STD HYD/ | Hydraulic-9cc | - | 2300 kg | 510 | - | 15 m/min | 15 m/min | 40 kg | - | 200 bar | 32 lt/min | CW |
3D Models
Deck Templates
