Capstan T1500
Main Features
- Motor IP-rating (12/24V): 66
- Anodised marine aluminium gearbox
- Control Box included in package
| Code | Description | Construction | Motor size | Power Supply | Maximum Pull | Working load (kg) | Amps at Working Load (A) | Line Speed at W.L | Max Line Speed | Net Weight | Circuit Breaker |
|---|---|---|---|---|---|---|---|---|---|---|---|
![[] CAPSTAN T1500 CRO STD 1500W/12V image](https://www.lofrans.com/images/items/itm_CapstanT500-1700.jpg)
|
CAPSTAN T1500 CRO STD 1500W/12V | Chromed bronze | 1500 W | 12 V | 1200 kg | 190 | 150 | 17 m/min | 40 m/min | 27 kg | 187333 |
|
|
CAPSTAN T1500 CRO STD 1500W/24V | Chromed bronze | 1500 W | 24 V | 1250 kg | 190 | 75 | 19 m/min | 40 m/min | 27 kg | 187332 |
|
|
CAPSTAN T1500 ALU STD 1500W/12V | Aluminium | 1500 W | 12 V | 1200 kg | 190 | 150 | 17 m/min | 40 m/min | 18 kg | 187333 |
|
|
CAPSTAN T1500 ALU STD 1500W/24V | Aluminium | 1500 W | 24 V | 1250 kg | 190 | 75 | 19 m/min | 40 m/min | 18 kg | 187332 |
3D Models
Deck Templates
