Capstan T1000
Main Features
- Luxury chrome bronze base and drum
- Heavy duty rated IP67 electric motor
- Anodised marine aluminium gearbox
- Control Box included in package
| Code | Description | Construction | Motor size | Power Supply | Maximum Pull | Working load (kg) | Amps at Working Load (A) | Line Speed at W.L | Max Line Speed | Net Weight | Circuit Breaker |
|---|---|---|---|---|---|---|---|---|---|---|---|
![[] CAPSTAN T1000 CRO STD 1000W/24V image](https://www.lofrans.com/images/items/itm_CapstanT500-1700.jpg)
|
CAPSTAN T1000 CRO STD 1000W/24V | Chromed bronze | 1000 W | 24 V | 1060 kg | 165 | 70 | 23 m/min | 40 m/min | 21 kg | 187332 |
|
|
CAPSTAN T1000 ALU STD 1000W/12V | Aluminium | 1000 W | 12 V | 1000 kg | 165 | 135 | 20 m/min | 40 m/min | 16 kg | 187333 |
|
|
CAPSTAN T1000 ALU STD 1000W/24V | Aluminium | 1000 W | 24 V | 1060 kg | 165 | 70 | 23 m/min | 40 m/min | 16 kg | 187332 |
|
|
CAPSTAN T1000 CRO STD 1000W/12V | Chromed bronze | 1000 W | 12 V | 1000 kg | 165 | 135 | 20 m/min | 40 m/min | 21 kg | 187333 |
3D Models
Deck Templates
