Capstan ST3000
Main Features
- Luxury 3 16L Stainless Steel base and drum
- Heavy duty electric motor
- Anodised marine aluminium gearbox
| Code | Description | Amps at Working Load (A) | Control Box | Hydraulic Flow | Hydraulic Pressure | Line Speed at W.L | Max Line Speed | Maximum Pull | Motor size | Net Weight | Power Supply | Working load (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
![[] CAPSTAN ST3000 2200W 400V 3PH 50HZ DECK THICK. 90MM CW image](https://www.lofrans.com/images/items/itm_CapstanT3000.jpg)
|
CAPSTAN ST3000 2200W 400V 3PH 50HZ DECK THICK. 90MM CW | - | Switchboard available separately | - | - | 16 m/min | 16 m/min | 2500 kg | 2200 W | 75 kg | 3PH 400V 50HZ | 550 |
|
|
CAPSTAN ST3000 S/S CR HYD | - | - | 32 lt/min | 200 bar | 17 m/min | 17 m/min | 3000 kg | Hydraulic-9cc | 40 kg | - | 650 |
| 602193 | CAPSTAN ST3000 2200W 400V 3PH 50HZ DECK THICK. 90MM CCW | 210 | Switchboard available separaterly | - | - | 14 m/min | 27 m/min | 3000 kg | 2200 W | 75 kg | 3PH 400V 50HZ | 600 |
|
|
CAPSTAN ST3000 S/S STD 3600W/400V | 210 | Switchboard available separaterly | - | - | 14 m/min | 27 m/min | 3000 kg | 3600 W | 75 kg | 3PH 400V 50HZ | 600 |
