Capstan ST2500
| Code | Description | Hydraulic Pressure | Hydraulic Flow | Type | Amps Work Load (A) | Net Weight with Drum (kg) | Motor size | Power Supply | Maximum Pull | Working load (kg) | Line Speed at W.L | Max Line Speed | Control Box |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![[] CAPSTAN ST2500 INOX STD 2200W/400V image](https://www.lofrans.com/images/items/itm_ST2500.jpg)
|
CAPSTAN ST2500 INOX STD 2200W/400V | - | - | cw | - | 52 | 2200 w | 400 V | 2200 | 595 | 15 | 15 | Switchboard available separately |
|
|
CAPSTAN ST2500 INOX STD 2700W/24V | - | - | cw | 210 | 53 | 2700 w | 24 V | 2400 | 650 | 15 | 31 | Included in package |
|
|
CAPSTAN ST2500 INOX STD HYD | 200 | 32 | cw | - | 40 | Hydraulic - 9cc | - | 2500 | 680 | 15 | 15 | - |
Product Brochure
