Capstan ST2000
Capstan ST2000_photo-0
Printer Friendly Version

Code Hydraulic Pressure Hydraulic Flow Type Amps Work Load (A) Net Weight with Drum (kg) Motor size Power Supply Maximum Pull Working load (kg) Line Speed at W.L Max Line Speed Control Box
636300 - - cw 180 52 2300 w 24 2000 545 15 31 Included in package
636301 - - ccw 180 52 2300 w 24 2000 545 15 31 Included in package
File
Installation And User's Manual ~ Capstans - T500, T700, T1000, T1500, T1700, T2000, T2500, ST1000, ST1500, ST1700, ST2000, ST2500, ST3000, ST4000 Download
Capstans ST Series Brochure Download
