Capstan ST2000
| Code | Description | Hydraulic Pressure | Hydraulic Flow | Type | Amps Work Load (A) | Net Weight with Drum (kg) | Motor size | Power Supply | Maximum Pull | Working load (kg) | Line Speed at W.L | Max Line Speed | Control Box |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![[] CAPSTAN ST2000 INOX STD 2300W/24V CW image](https://www.lofrans.com/images/items/itm_ST1500-ST1700-ST2000.jpg)
|
CAPSTAN ST2000 INOX STD 2300W/24V CW | - | - | cw | 180 | 52 | 2300 w | 24 | 2000 | 545 | 15 | 31 | Included in package |
|
|
CAPSTAN ST2000 INOX CCW 2300W/24V | - | - | ccw | 180 | 52 | 2300 w | 24 | 2000 | 545 | 15 | 31 | Included in package |
