Capstan T2000

Main Features

  • Luxury chromed bronze construction base and drum
  • Heavy duty electric motor
  • Anodised marine aluminium gearbox
Capstan T2000_photo-0




Printer Friendly Version

Code Control Box Hydraulic Flow Hydraulic Pressure Line Speed at W.L Max Line Speed Maximum Pull Motor size Net Weight Power Supply Pull Type Amps at Working Load (A) Working load (kg)
404967 Included in package - - 15 m/min 31 m/min 2000 kg 2300 W 52 kg 24 V CW 180 410
600071 Switchboard available separately - - 15 m/min 15 m/min 2000 kg 2200 W 52 kg 230-400 V CW - 410
600729 Included in package - - 15 m/min 31 m/min 2000 kg 2300 W 52 kg 24 V CCW 180 410
602140 - 32 lt/min 200 bar 15 m/min 15 m/min 2300 kg Hydraulic-9cc 40 kg - CW - 510
File
Installation And User's Manual ~ Capstans - T500, T700, T1000, T1500, T1700, T2000, T2500, ST1000, ST1500, ST1700, ST2000, ST2500, ST3000, ST4000 Download
3D CAD Model ~ T2000 Download
Deck Template ~ T2000 (dwg) Download
Deck Template ~ T2000 (pdf) Download


Accessories

Foot Switch
Foot Switch
Learn more...
Control Switch
Control Switch
Learn more...
Radio Remote Control
Radio Remote Control
Learn more...
