Capstan T1700

Main Features

  • Motor IP-rating (12/24V): 66
  • Anodised marine aluminium gearbox
  • Control Box included in package
Capstan T1700_photo-0
Printer Friendly Version

Code Amps at Working Load (A) Circuit Breaker Construction Line Speed at W.L Max Line Speed Maximum Pull Motor size Net Weight Power Supply Working load (kg)
187326 90 187332 Chromed bronze 15 m/min 32 m/min 1695 kg 1700 W 30 kg 24 V 270
472407 180 187334 Chromed bronze 14 m/min 32 m/min 1600 kg 1700 W 30 kg 12 V 270
600066 180 187334 Aluminium 14 m/min 32 m/min 1600 kg 1700 W 25 kg 12 V 270
600069 90 187332 Aluminium 15 m/min 32 m/min 1695 kg 1700 W 25 kg 24 V 270
File
Installation And User's Manual ~ Capstans - T500, T700, T1000, T1500, T1700, T2000, T2500, ST1000, ST1500, ST1700, ST2000, ST2500, ST3000, ST4000 Download
3D CAD Model ~ T1700 Download
Deck Template ~ T1700 (dwg) Download
Deck Template ~ T1700 (pdf) Download


Accessories

Foot Switch
Foot Switch
Learn more...
Control Switch
Control Switch
Learn more...
Radio Remote Control
Radio Remote Control
Learn more...
