Capstan T1000

Main Features

  • Luxury chrome bronze base and drum
  • Heavy duty rated IP67 electric motor
  • Anodised marine aluminium gearbox
  • Control Box included in package
Capstan T1000_photo-0




Printer Friendly Version

Code Working Load (A) Circuit Breaker Construction Line Speed at W.L Max Line Speed Maximum Pull Motor size Net Weight Power Supply Working load (kg)
187324 70 187332 Chromed bronze 23 m/min 40 m/min 1060 kg 1000 W 21 kg 24 V 165
409564 135 187333 Aluminium 20 m/min 40 m/min 1000 kg 1000 W 16 kg 12 V 165
409567 70 187332 Aluminium 23 m/min 40 m/min 1060 kg 1000 W 16 kg 24 V 165
417946 135 187333 Chromed bronze 20 m/min 40 m/min 1000 kg 1000 W 21 kg 12 V 165
File
Installation And User's Manual ~ Capstans - T500, T700, T1000, T1500, T1700, T2000, T2500, ST1000, ST1500, ST1700, ST2000, ST2500, ST3000, ST4000 Download
3D CAD Model ~ T1000 Download
Deck Template ~ T1000 (dwg) Download
Deck Template ~ T1000 (pdf) Download
Model A B C D G H I J L
T1000 135 25-40 150 Ø92 62 256 Ø155 134 157

Accessories

Foot Switch
Foot Switch
Learn more...
Control Switch
Control Switch
Learn more...
Radio Remote Control
Radio Remote Control
Learn more...
