CAYMAN - Horizontal Windlass

CAYMAN - Horizontal Windlass

Main Features:

  • Marine aluminium anodised body
  • Indepent Gypsy and drum operation
  • Manual chain release
  • Manual override
  • Heavy duty rated IP66 electric motor
  • Automatic free fall available as option
  • Control Box included in package

CAYMAN - Horizontal Windlass_photo-0

To select the proper anchor windlass, you must determine whether it's for a light or heavy use, so we have created a Windlass Selection Tool to help you. Please note that this tool offers recommendations; for your final windlass selection, your local distributor will be able to advise and assist you.


Code Amps at Working Load (A) Circuit Breaker Gypsy For Chain Line Speed at W.L Max Line Speed Maximum Pull Motor size Net Weight Power Supply Type Working load (kg)
220273 110 187332 8 mm, ISO 4565
DIN 766
21 m/min 32 m/min 1000 kg 700 W 24 kg 12 V With Drum 100
220279 150 187333 8 mm, ISO 4565
DIN 766
16 m/min 32 m/min 1250 kg 1000 W 25 kg 12 V With Drum 170
419732 150 187333 10 mm, ISO 4565 16 m/min 32 m/min 1250 kg 1000 W 25 kg 12 V With Drum 170
600043 110 187332 6 mm, ISO 4565
DIN 766
21 m/min 32 m/min 1000 kg 700 W 24 kg 12 V With Drum 100
600165 150 187333 10 mm, DIN 766 16 m/min 32 m/min 1250 kg 1000 W 25 kg 12 V With Drum 170
600180 80 187332 10 mm, DIN 766 17 m/min 33 m/min 1325 kg 1000 W 25 kg 24 V With Drum 170
File
Installation And User's Manual _ LION 1000 - Tigres - Cayman - Falkon Download
Lofrans' Oil Capacities Download
3D CAD Model ~ Cayman Download
Deck Template ~ Cayman (dwg) Download
Deck Template ~ Cayman (pdf) Download
