Capstan T700

Main Features

  • Luxury chrome bronze base and drum
  • Heavy duty rated IP67 electric motor
  • Anodised marine aluminium gearbox
  • Control Box included in package
Capstan T700_photo-0




Printer Friendly Version

Code Amps at Working Load (A) Circuit Breaker Construction Line Speed at W.L Max Line Speed Maximum Pull Motor size Net Weight Power Supply Working load (kg)
220006 110 187331 Chromed bronze 20 m/min 30 m/min 850 kg 700 W 15 kg 12 V 115
411129 110 187331 Aluminium 20 m/min 30 m/min 850 kg 700 W 15 kg 12 V 115
418159 50 187332 Chromed bronze 23 m/min 30 m/min 900 kg 700 W 15 kg 24 V 115
600779 50 187332 Aluminium 23 m/min 30 m/min 900 kg 700 W 15 kg 24 V 115
File
Installation And User's Manual ~ Capstans - T500, T700, T1000, T1500, T1700, T2000, T2500, ST1000, ST1500, ST1700, ST2000, ST2500, ST3000, ST4000 Download
3D CAD Model ~ T700 Download
Deck Template ~ T700 (dwg) Download
Deck Template ~ T700 (pdf) Download


Accessories

Foot Switch
Foot Switch
Learn more...
Control Switch
Control Switch
Learn more...
Radio Remote Control
Radio Remote Control
Learn more...
